Monday, December 02, 2013

On The First Class of Service the Network Gave to Me…

By: John Shepler

One of the big impediments in getting networks to work well for all types of traffic is that different types of traffic have different needs. Treat all packets the same and you’ll enjoy excellent results in some cases and unacceptable results in others. What’s the solution? You need to add a touch of class to your network.

Get control of your MAN and WAN network traffic with class of service solutions.The idea behind class of service or CoS is that different types of traffic get different priorities on the network. For instance, do you really think that data backups are as sensitive to network characteristics such as latency and jitter as VoIP telephone conservations? Of course not. If your network has the capacity it may not matter. With infinite bandwidth all traffic will flow smoothly from source to destination. The problem is that we don’t have infinite bandwidth or infinitely large anything else.

This really shows up in MAN and WAN connections. These telecom links are almost always more limited than your LAN resources simply because of the cost involved. How many companies can afford 10 or 100 Gbps private lines cross-country? In fact, even 1 Gbps is a stretch for many IT departments. Many companies will have to get everything done with 10 Mbps Ethernet or 100 Mbps Fast Ethernet MAN and WAN service.

Can this work? It likely can if you carefully manage your traffic and don’t have so much that you saturate the network. The trick is in establishing multiple classes of service and assigning each type of traffic to one of those classes. Do it right and everything on the network will run smoothly.

The simplest example is to establish two classes of service. One is for latency sensitive applications. The other is for everything else. A good example is a SIP trunk that provides you with both VoIP business phone service and Internet access. This is becoming a popular setup for smaller business locations because of the cost savings involved in having only one outside trunk line. The VoIP traffic is extremely sensitive to latency and jitter so it goes into the class that has priority. Most of what you do on the Internet isn’t that sensitive, so it goes into the non-priority class.

You need this type of division because voice traffic is typically low bandwidth per conversation and will break up if there is any network congestion. Data transfers and web page downloads aren’t so sensitive to congestion and will take all the bandwidth they can get. If there isn't enough, they may slow down a bit but you won’t lose any data.

Class of Service keeps the big data and video downloads from pushing the more sensitive voice and two-way video conferences to the side. This can make your network perform much better overall without increasing bandwidth. Even so, there’s no free lunch. When the network gets congested enough, you are going to notice the slowdown on non-critical traffic and will have to increase bandwidth to make everything run as fast as it can.

Class of Service is one of the big differentiators between the Internet and private networks. There is no CoS on the Internet. In fact, it is a matter of pride that all packets are treated equally. This principle is called network neutrality. It makes the public Internet fair for all users, but inhibits performance on latency and bandwidth sensitive applications.

Is there a reason to create more than two classes of service? There is for more sophisticated operations. XO Communications is offering what they call Premium CoS with six different classes.

At the lowest level is standard class service for data and Internet traffic. The next step up is Priority class for data and Internet traffic that has a more urgent need to get through quickly, such as email messaging. Up from that is Priority Plus for traffic that has some sensitivity to delay and jitter such as FTP transfers.

Critical, the next class up, is for business applications such as SAP that will affect productivity if they are delayed. Critical Plus goes a step higher for applications such as Telnet Routing Protocols. The real time applications are at the top of the heap for priority. These include voice and two-way video. One way video can take a lower class because it is easily buffered to compensate for most jitter and latency issues.

Are you frustrated by the problems that have arisen as you’ve expanded the expectations of what types of traffic your network is expected to handle, especially for MAN and WAN connections? If so, a private network with two or more classes of service may get everything running smoothly again at a reasonable cost. Get more information about MAN and WAN class of service network solutions, along with pricing and availability.

Click to check pricing and features or get support from a Telarus product specialist.

Note: Photo of high speed traffic courtesy of Wikimedia Commons.
